FRAME MATERIALS:  Main frame – 2x3” 11-gauge oval tubular steel with a combination of 2x2” round tubing.

WELDS:  All welded construction by inert-gas MIG welding conforming with all Structural Welding Code-Steel Standards and Specifications.

FINISH:  Eight-step electrostatically applied powder coat finish.

FRAME COLORS:  Main frame:  Platinum Sparkle   Accent:  Cathedral Gray

UPHOLSTERY:  Premium grade naugahyde formulated to resist bacteria, stains, mildew and oil. Meets most flammability test requirements. Standard two-tone (Black/Cadet) and double-stitched with “hidden” borders. Custom colors (one-tone) are available – inquire with your sales representative.

PADDING:  High density 2” thick rebond urethane foam glued to 1” industrial plywood backing, trimmed and formed to exact fit.

ADJUSTMENT PINS:  1/2” push-pull spring loaded solid steel adjustment pins with ultimate load of 9040 lbs. and 46042 psi sheer strength.

BEARINGS:  1” solid steel pivot axles with non-friction 2” sealed bearings (load rating of 2400 lbs.) internally encased on primary pivots, and oil-impregnated bronze bushings on all secondary pivots.

GUIDE RODS:  3/4” solid steel 1045 (tgp) highly polished chrome-plated finish.

• a combination of 2x2” round tubing.

  WELDS:  All welded construction by inert-gas MIG welding conforming with all Structural Welding Code-Steel Standards and Specifications.

  FINISH:  Eight-step electrostatically applied powder coat finish.

  FRAME COLORS:  Main frame:  Platinum Sparkle   Accent:  Cathedral Gray

  UPHOLSTERY:  Premium grade naugahyde formulated to resist bacteria, stains, mildew and oil. Meets most flammability test requirements. Standard two-tone (Black/Cadet) and double-stitched with “hidden” borders. Custom colors (one-tone) are available – inquire with your sales representative.

  PADDING:  High density 2” thick rebond urethane foam glued to 1” industrial plywood backing, trimmed and formed to exact fit.

  ADJUSTMENT PINS:  1/2” push-pull spring loaded solid steel adjustment pins with ultimate load of 9040 lbs. and 46042 psi sheer strength.

  BEARINGS:  1” solid steel pivot axles with non-friction 2” sealed bearings (load rating of 2400 lbs.) internally encased on primary pivots, and oil-impregnated bronze bushings on all secondary pivots.

  GUIDE RODS:  3/4” solid steel 1045 (tgp) highly polished chrome-plated finish.



• CABLES:  2200 lbs. test 3/16” military-spec nylon coated cable.

  PULLEYS:  4-1/2” and 3-1/2” fiberglass-impregnated nylon pulleys with double sealed roller bearings.

  SELECTOR WEIGHT PINS:  Solid steel, magnetic with ball-end to ensure a tight connection and secure fit. Coiled lanyard helps prevent pin removal and loss.

  FASTENERS:  All frame bolts and nuts are 3/8” and 1/2” zinc plated. Meets ANSI specifications.

  WEIGHT STACK:  Black painted solid steel weight plates with self aligning low friction sleeves.
