PPF-706 PREACHER CURL BENCH

FRAME MATERIALS:  Main  frame  – 2x4” 11-gauge 120 wall oval tubular steel with a combination of 2” round and other 11-gauge tubular steel.

WELDS:  All welded construction conforming with all Structural Welding Code-Steel Standards and Specifications.

PADDING:  High density 1” thick 3 lbs. rebond urethane foam glued to 1” industrial plywood backing, trimmed and formed to exact fit.

CABLES & BELTS:  Cable driven units – USA-Made/Certified 3/16” and 1/4” EXERFLEX PRO® high performance fitness cable rated at 4200 lbs. tensile strength. Belt driven units: reinforced Kevlar® belts, rated at 4400 lbs. tensile strength.

GUIDE RODS:  3/4” solid steel 1045 (tgp) highly polished hard chrome finish.

FINISH:  Powder coat finish baked at 400ºF and carefully monitored to ensure complete curing.

FRAME COLORS:  Custom two tone finish offers choice of six primary colors combined with Charcoal Texture accents. Custom colors available, please inquire with your sales representative.

UPHOLSTERY:  Premium Bolta Sport vinyl with PreFixx, formulated to resist bacteria, stains, mildew, oil and UV stabilized pigments. Meets most flammability test requirements. All upholsteries are double-stitched with “hidden” borders. Bolta Sport color swatches are available upon request. Sixteen standard colors. Custom colors are available – please inquire with your sales representative.

ADJUSTMENT PINS:  1/2” and 5/8” push-pull spring loaded solid steel adjustment pins  with ultimate load of 9040 lbs. and 46042 psi sheer strength.

BEARINGS:  1” solid stainless steel pivot axles with non-friction 2” sealed bearings (load rating of 2400 lbs.) internally encased on primary pivots, and oil-impregnated bronze bushings on all secondary pivots.

PULLEYS:  Combination wide grove fiberglass reinforced nylon pulleys on belt-driven system and solid aluminum pulleys on cable units.

CAMS:  Charcoal Texture powder coat solid aluminum variable resistance cam designed specifically for each machine.

FASTENERS:  All frame bolts and nuts are 3/8” and 1/2” blue zinc plated grade 8 and up. Meets ANSI specifications.

CUSTOM STABILIZER FEET:  Heavy-duty molded rubber base feet insure stability, prevent equipment movement, and may be bolted to the floor.

SELECTOR WEIGHT PINS:  Weight pins are solid steel, magnetic with ball-end to ensure a tight connection and secure fit. Coiled lanyard helps prevent pin removal and loss.

WEIGHT STACK:  Black painted solid steel weight plates with self aligning low friction sleeves. Weight upgrades available, call for availability.
